Direct Drive Premium Efficiency Centrifugal Upblast ECM Exhaust Fan 500-800 CFM, 1/4HP, 1PH
SKU:
10D-ECA

HoodMart Hoods are Guaranteed To Pass ALL City & State Codes.
Quality Hoods You Can Trust, Quick Delivery... NSF, UL, NFPA & ETL APPROVED!

Worried about installation? Building Permits? State or City Codes? No problem.
Concerned about working with Inspectors? No Problem.
The HoodMart Team can coordinate installation of makeup air hoods with fire suppression systems, saving you valuable time and money.

High Efficiency Direct Drive Centrifugal Drive Upblast Fans are constructed with heavy gauge spun aluminum and can be used as a rooftop or wall mount. This fan is ideal for exhausting air from restaurants, offices, warehouses, or commercial buildings. The EC fan motors offer true variable speed operation. Horsepower ranges from 1/4hp to 1hp. All motors single phase and can be operated at 50 or 60 Hz. Exhaust fans are code compliant and are Listed UL762 for restaurant applications.

SERVING restaurant owners, contractors, architects and professional installers nationwide!

EC20 Direct Drive Single Phase


Your Roof Exhaust fans Include:

  • Spun aluminum housing will not rust, chip or peel.
  • Aluminum backward inclined wheel is non-overloading Quick release latches for easy motor access All units can be wall mounted.
  • Made in USA
  • All motors are 1 Phase 120/240V operation and can be operated at 50 or 60 Hz.
  • EC motors offer true variable speed operation and up to 70% energy savings over PSC motors.
  • On-board speed adjustment allows simple setup and balancing with LED display.
  • Can be controlled remotely up to 50’ using a remote mount potentiometer or 0-10V.
  • OPTIONAL ACCESSORIES • Grease extractor • Curb hinge • Roof Curb
  • 2 Year Warranty

Product Overview

HoodMart offers a full line of Quality Fans You Can Trust, Quick Delivery... NSF, UL, NFPA & ETL APPROVED!

Premium Efficiency (UL762) exhaust fans with ECM (Electrically Commuted Motors) are constructed with heavy gauge spun aluminum can be used as a rooftop or wall mount. This fan is ideal for exhausting air from restaurants, offices, warehouses, or commercial buildings. The EC fan motors offer true variable speed operation with a 70% energy savings over PSC motors. Horsepower ranges from 1/4hp to 1hp. All motors single phase and can be operated at 50 or 60 Hz. Exhaust fans are code compliant and are Listed UL762 for restaurant applications.

SERVING restaurant owners, contractors, architects, and professional installers nationwide!

Worried about installation? Building Permits? State or City Codes? No problem.
Concerned about working with Inspectors? No Problem.
Call your Hoodmart representative today!

LET US HELP YOU

Help | How Can We Help You

How Can We Help You?

What Type of Hood Do You Need?

Help | Experts Are Ready to Help You

Experts Are Ready to Help You:

Custom Size Hoods

Ship in 5-7 Business Days.

Talk To A Specialist

Factory Support For All Questions.

CALL 24/7 1.800.715.1014

Direct Drive Premium Efficiency Centrifugal Upblast ECM Exhaust Fan 500-800 CFM, 1/4HP, 1PH

SKU:
10D-ECA
Orig.Price $1,086.96 Your Price $1,000.00

Availability: In stock, ready to be shipped

Shipping Estimator
FreeShipping
In stock
Direct Drive Premium Efficiency Centrifugal Upblast ECM Exhaust Fan 500-800 CFM, 1/4HP, 1PH 10D-ECA SHOP HOODS, EXHAUST/SUPPLY FANS, Exhaust Fans, Premium Efficiency Direct Drive Restaurant Exhaust Fans
Direct Drive Premium Efficiency Centrifugal Upblast ECM Exhaust Fan 500-800 CFM, 1/4HP, 1PH 10D-ECA SHOP HOODS, EXHAUST/SUPPLY FANS, Exhaust Fans, Premium Efficiency Direct Drive Restaurant Exhaust Fans

HoodMart Hoods are Guaranteed To Pass ALL City & State Codes.
Quality Hoods You Can Trust, Quick Delivery... NSF, UL, NFPA & ETL APPROVED!

Worried about installation? Building Permits? State or City Codes? No problem.
Concerned about working with Inspectors? No Problem.
The HoodMart Team can coordinate installation of makeup air hoods with fire suppression systems, saving you valuable time and money.

High Efficiency Direct Drive Centrifugal Drive Upblast Fans are constructed with heavy gauge spun aluminum and can be used as a rooftop or wall mount. This fan is ideal for exhausting air from restaurants, offices, warehouses, or commercial buildings. The EC fan motors offer true variable speed operation. Horsepower ranges from 1/4hp to 1hp. All motors single phase and can be operated at 50 or 60 Hz. Exhaust fans are code compliant and are Listed UL762 for restaurant applications.

SERVING restaurant owners, contractors, architects and professional installers nationwide!

EC20 Direct Drive Single Phase


Your Roof Exhaust fans Include:

  • Spun aluminum housing will not rust, chip or peel.
  • Aluminum backward inclined wheel is non-overloading Quick release latches for easy motor access All units can be wall mounted.
  • Made in USA
  • All motors are 1 Phase 120/240V operation and can be operated at 50 or 60 Hz.
  • EC motors offer true variable speed operation and up to 70% energy savings over PSC motors.
  • On-board speed adjustment allows simple setup and balancing with LED display.
  • Can be controlled remotely up to 50’ using a remote mount potentiometer or 0-10V.
  • OPTIONAL ACCESSORIES • Grease extractor • Curb hinge • Roof Curb
  • 2 Year Warranty

Product Overview

HoodMart offers a full line of Quality Fans You Can Trust, Quick Delivery... NSF, UL, NFPA & ETL APPROVED!

Premium Efficiency (UL762) exhaust fans with ECM (Electrically Commuted Motors) are constructed with heavy gauge spun aluminum can be used as a rooftop or wall mount. This fan is ideal for exhausting air from restaurants, offices, warehouses, or commercial buildings. The EC fan motors offer true variable speed operation with a 70% energy savings over PSC motors. Horsepower ranges from 1/4hp to 1hp. All motors single phase and can be operated at 50 or 60 Hz. Exhaust fans are code compliant and are Listed UL762 for restaurant applications.

SERVING restaurant owners, contractors, architects, and professional installers nationwide!

Worried about installation? Building Permits? State or City Codes? No problem.
Concerned about working with Inspectors? No Problem.
Call your Hoodmart representative today!
